E-One (formerly Emergency One) is a fire apparatus manufacturer located in Ocala, Florida. One of the largest fire apparatus manufacturers in the world, E-One trucks can be found in many countries, with over 25,000 units in service globally.
History[]
Formed in 1974 by retired playground equipment manufacturer Robert Wormser, Emergency One grew quickly and became the largest fire apparatus builder in the United States by the mid-1980s. The company pioneered the use of modular bodies built from extruded aluminum components, enabling it to build in advance and speed up production time considerably. It built a new 75,000 square foot plant in Ocala to meet production needs in 1978. A new line of aerial devices was launched in 1981 - the company had built earlier aerial-equipped apparatus using ladder assemblies purchased from an outside supplier. The Hurricane custom chassis was introduced in 1984, leading to a full line of custom trucks.
Corporately, in 1979, Emergency One was acquired by the Federal Signal Corporation. The chassis business was spun off into a separate entity called Federal Motors in 1985, and Emergency One officially changed its name to E-One in 1988. From the 1980s to the 1990s, E-One also manufactured a line of ambulances.
In the late 1980s, E-One began to acquire other apparatus manufacturers. In 1989, it purchased Florida-based American Eagle. In late 1991, E-One entered the Canadian market in force with its purchase of Superior Emergency Vehicles. In 1998, Saulsbury Fire and Rescue Corporation of Preble, NY was added to the E-One family. The three plants purchased were closed in 1992, 2006 and 2004, respectively.
In 2008, E-One was purchased by AIP in a carve out from Federal Signal. It was assigned to AIP's REV Group portfolio. AIP is a private equity firm distinctively focused on buying and improving industrial businesses with operations in the United States or Canada. The REV Group portfolio is a leading diversified manufacturer of specialty vehicles to North America, as well as export markets.
In the early 2020s, E-One introduced "AFT" (America's Fire Truck) as a front fascia styling for the Spartan FC-94 chassis. In 2022, E-One introduced the Vector, touted as the first fully-electric, North American-style fire truck.
In 2024, E-One celebrated its 50th anniversary.
Facilities[]
E-One builds a full line of trucks from plants in Ocala, FL and Hamburg, NY. The Hamburg facility builds all stainless steel pumpers, rescues, and tankers. All other products are manufactured in Ocala.
Logos[]
.JPG "Modern EOne (3).JPG (2.64 MB)")
Production[]
E-One produces a full line of fire apparatus and its own brand of custom chassis. Over 28,000 units have been built since 1974. The company also builds on commercial chassis and has in the past used other custom chassis, including Spartan, Pemfab and Simon-Duplex.
Custom chassis[]
Current[]
- E-One Cyclone (1985-present)
- E-One Titan (ARFF) (1985-present)
- E-One Typhoon (2002-present)
- E-One Vector (2022-Present) (Available with Cyclone or Typhoon)
Discontinued[]
- E-One Daytona (1999)
- E-One HS (2015-2021) (Available with Cyclone or Quest cabs)
- E-One Hush (mid-engine) (1999-2015) (Available with Cyclone II, Typhoon, or Quest)
- E-One Hush (rear-engine) (1985-1999) (Available with Cyclone, then Cyclone II (1997-1999))
- E-One Hurricane (1984-2007)
- E-One Protector (1990-2002)
- E-One Quest (2007-2021)
- E-One Sentry (1993-1996)
Aerials[]
- All pump/tank measurements are in US gallons.
- Payload capacities are denoted by firefighter weight + equipment allowance
Select Series[]
E-One's Select Series aerials are designed to simplify the quoting process in order to expedite delivery.
| HP 75 | HP 78 | Metro 100 Quint | HR 100 Tandem | |
|---|---|---|---|---|
| Custom Chassis | Cyclone or Typhoon (58" medium or 67.5" long cabs, barrier or full height doors, flat or split 12" raised roof)
| |||
| Engine | Cummins X10 (450 HP)
| |||
| Gross Axle Weight Rating (GAWR) | 21,500 lb. front; 33,000 lb. rear | 21,500 lb. front; 33,000 lb. rear | 24,000 lb. front; 35,000 lb. rear | 22,800 lb. front; 48,000 lb. rear |
| Overall Length / Height | - 37' 1" OAL - 11' 4" OAH |
- 37' 1" OAL - 11' 7" OAH |
- 39' 4" to 40' 1" OAL - 11' 7" to 11' 10" OAH |
- 40' 10" to 42' 2" OAL - 11' 7" OAH |
| Rear Axle & Wheelbase |
Single 210 or 220" |
Single 220 or 230" |
Single 235 or 245" |
Tandem 230 or 240" |
| Aerial Extension Capacity | 75' vertical 70' 2" horizontal |
78' vertical 70' 2" horizontal |
100' vertical 92' horizontal |
100' vertical 92' horizontal |
| Payload Capacity | 500+75 lbs dry or wet (1500 GPM flow) | 750+75 lbs dry 500+75 lbs wet (1500 GPM flow) |
500+75 lbs dry or wet (1500 GPM flow) | 500+75 lbs dry or wet (1500 GPM flow) |
| Stabilizers | 1x set H-style outriggers (16' spread) | 1x set H-style outriggers (16' spread) | 2x sets criss-cross underslung outriggers (11' spread) | 2x sets criss-cross underslung outriggers (12' spread) |
| Body | Quint w/ SideStacker hose bed
| |||
| Pump | Hale or Waterous; 1500 or 2000 GPM (6000 LPM optional)
| |||
| Tank (water/optional foam) | 500 or 470/30 | 500 or 470/30 | 470 or 450/20 | 500 or 480/20 |
Ladders[]
| HP 75 | HP 78 | Metro 100 | Metro HR 100 | Metro 100 Quint | Metro 110 | 100 or 110 Tandem | CR 100 | CR 137 | |
|---|---|---|---|---|---|---|---|---|---|
| Aerial Device | - | - | LTH 100 ladder | - | 1) HR 100 ladder 2) LTH 100 ladder 3) 110 ladder |
- | 1) HR 100 ladder 2) LTH 100 ladder 3) 110 ladder |
- | - |
| Custom Chassis | Cyclone or Typhoon (58" medium to 80" extended length cabs, barrier or full height doors, flat or split 12" raised roof)
|
Cyclone or Typhoon (58" medium or 67.5" long cabs, barrier or full height doors, flat or split 12" raised roof. Longer cabs available for tandem axle units with no pump/no tank configuration)
| |||||||
| Engine | Cummins X10 (400 or 450 HP)
Cummins X15 (565 or 605 HP) |
Cummins X10 (450 HP)
Cummins X15 (565 or 605 HP) | |||||||
| Gross Axle Weight Rating (GAWR) | 20,000 to 24,000 lb. front; 33,000 or 35,000 lb. rear | 20,000 to 24,000 lb. front; 33,000 or 35,000 lb. rear | 20,000 to 24,000 lb. front; 33,000 lb. rear | 21,000 to 24,000 lb. front; 33,000 or 35,000 lb. rear | 24,000 lb. front; 35,000 lb. rear | 20,000 to 24,000 lb. front; 33,000 lb. rear | 20,000 to 24,000 lb. front; 48,000 to 52, 000 lb. rear | 21,000 to 24,000 lb. front; 52,000 or 54, 000 lb. rear | 21,000 to 24,000 lb. front; 52,000 or 54, 000 lb. rear |
| Overall Length / Height | - 37' 1" OAL - 11' 4" OAH |
- 37' 1" OAL - 11' 4" OAH |
- 38' 6" OAL - 10' 7" to 10' 10" OAH |
- 39' 4" to 40' 1" OAL - 11' 7" to 11' 10" OAH |
- 39' 4" to 40' 1" OAL - 11' 7" to 11' 10" OAH |
- 37' 4" OAL - 10' 11" or 11' 2" OAH |
- 40' 9" OAL - 11' 3" or 11' 7" OAH |
- 42' 10" OAL - 11' 10" OAH |
- 44' 7" OAL - 11' 10" OAH |
| Rear Axle & Wheelbase |
Single 210 to 230" |
Single 220 to 230" |
Single 220 to 230" |
Single 235 or 245" |
Single 235 or 245" |
Single 220 to 230" |
Tandem 230 or 240" |
Tandem 245 or 250" |
Tandem 245 or 250" |
| Aerial Extension Capacity | 75' vertical 70' 2" horizontal |
78' vertical 70' 2" horizontal |
100' vertical 92' horizontal |
100' vertical 92' horizontal |
100' or 110' vertical 92' or 102' horizontal |
110' vertical 102' horizontal |
100' or 110' vertical 92' or 102' horizontal |
100' vertical 91' 6" horizontal |
137' vertical 126' horizontal |
| Payload Capacity | 500+75 lbs dry or wet (1500 GPM flow) | 750+75 lbs dry 500+75 lbs wet (1500 GPM flow) |
250+75 lbs dry (optional waterway w/ 1500 GPM flow) | 500+75 lbs dry or wet (1500 GPM flow) | 1) HR 100: 500+75 lbs dry or wet (1500 GPM flow), up to 750 lbs dry w/ 85' side reach 2) LTH 100: 250+75 lbs dry (optional waterway w/ 1500 GPM flow) 3) 110 Ladder: 250+50 lbs dry (optional waterway w/ 1500 GPM flow) |
250+50 lbs dry (optional waterway w/ 1500 GPM flow) | 1) HR 100: 500+75 lbs dry or wet (1500 GPM flow), up to 750 lbs dry w/ 85' side reach 2) LTH 100: 250+75 lbs dry (optional waterway w/ 1500 GPM flow) 3) 110 Ladder: 250+50 lbs dry (optional waterway w/ 1500 GPM flow) |
750+75 lbs dry 500+75 lbs wet (1500 GPM flow) |
250+75 lbs dry (fixed waterway w/ 1500 GPM flow) |
| Stabilizers | 1x set H-style outriggers (16' spread) | 1x set H-style outriggers (16' spread) | 2x sets criss-cross underslung outriggers (11' spread) | 2x sets criss-cross underslung outriggers (11' spread) | 2x sets criss-cross underslung outriggers (11' spread) | 2x sets criss-cross underslung outriggers (11' spread) | 2x sets criss-cross underslung outriggers (12' spread) | 2x sets criss-cross underslung outriggers (13' 8" spread) | 2x sets criss-cross underslung outriggers (13' 8" spread) |
| Body | Quint w/ SideStacker or center hose bed | Quint w/ SideStacker or center hose bed | Truck w/ full depth compartments each side | Truck w/ full depth compartments each side | Quint w/ SideStacker hose bed | Truck w/ full depth compartments each side | Quint or Truck | Quint or Truck | Quint or Truck |
| Pump | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Not Applicable | Not Applicable | Hale up to 1500 GPM or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Not Applicable | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) |
| Tank | Up to 500 gallons | Up to 500 gallons | Not Applicable | Not Applicable | Up to 470 gallons standard (500 gallons optional w/ 85' side reach) | Not Applicable | 500 gallons standard (300 gallons optional) | 300 to 500 gallons | 300 to 500 gallons |
Platforms[]
| 95-Platform | HP 100 Platform | HP 95 Mid-Mount Platform | |
|---|---|---|---|
| Custom Chassis | Cyclone or Typhoon (58" medium or 67.5" long cabs, barrier or full height doors, flat or split 12" raised roof. Longer cabs available for no pump/no tank configuration)
|
Cyclone or Typhoon (58" medium or 67.5" long cabs, barrier or full height doors, flat or 12" vista roof)
| |
| Engine | Cummins X10 (450 HP)
Cummins X15 (565 or 605 HP) | ||
| Gross Axle Weight Rating (GAWR) | 21,000 to 24,000 lb. front; 52,000 or 54, 000 lb. rear | 21,000 to 24,000 lb. front; 54,000 or 62, 000 lb. rear | 1) 24,000 lb. front; 62, 000 lb. rear (quint) 2) 22,800 or 24,000 lb. front; 54,000 lb. rear (truck) |
| Overall Length / Height | - 46' OAL - 11' 10" OAH |
- 46' 11" OAL - 11' 11" to 12' 1" OAH |
- 46' 10" OAL - 10' 10" OAH (1' lower w/o pump) |
| Rear Axle & Wheelbase |
Tandem 245 or 250" |
Tandem 250, 252, or 260" |
Tandem 255 or 265" |
| Aerial Extension Capacity | 92' vertical 82' 6" horizontal |
100' vertical 91' 6" horizontal |
95' vertical 86' horizontal |
| Payload Capacity | 750+275 lbs dry 500+275 lbs wet (2000 GPM flow) |
1000+305 lbs dry 500+305 lbs wet (2000 GPM flow) |
1000+305 lbs dry 500+305 lbs wet (2000 GPM flow) |
| Stabilizers | 2x sets criss-cross underslung outriggers (13'-8" spread) | 2x sets criss-cross underslung outriggers (15'-6" spread) | 1x set criss-cross underslung outriggers (18' spread), 1x set H-style outriggers (11'-7" spread) |
| Body | 1) Quint w/ SideStacker or center hose bed 2) Truck |
1) Quint w/ SideStacker hose bed 2) Truck |
1) Quint w/ SideStacker hose bed 2) Truck |
| Pump | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Darley, Hale, or Waterous up to 2000 GPM (IGPM/LPM ratings optional) | Hale or Waterous up to 2000 GPM (IGPM/LPM ratings optional) |
| Tank | 300 to 500 gallons | 300 to 500 gallons | 300 to 500 gallons |
Tractor-Drawn Aerials[]
| HR 100 Tractor-Drawn | 110 Tractor-Drawn | |
|---|---|---|
| Custom Chassis | Cyclone or Typhoon (58" medium or 67.5" long cabs, barrier or full height doors, flat or 12" vista roof)
| |
| Engine | Cummins X10 (400 or 450 HP)
Cummins X15 (565 or 605 HP) | |
| Gross Axle Weight Rating (GAWR) | 1) 20,000 to 21,500 lb. front; 31,000 lb. rear (w/o pump/tank) 2) 22,800 to 24,000 lb. front; 35,000 lb. rear (w/ pump/tank) |
20,000 to 21,500 lb. front; 31,000 lb. rear |
| Overall Length / Height | - 59' 3" to 63' OAL - 11' 5" to 11' 8" OAH |
- 57' 5" to 58' 3" OAL - 10' 11" to 11' 2" OAH |
| Tractor Wheelbase | 1) 151 or 161" (w/o pump/tank) 2) 186 or 196" (w/ pump/tank) |
151 or 161" |
| Trailer Wheelbase | 365" | 343" |
| Tiller Cab | 57" standard height (54" optional); sliding or hinged doors | 57" standard height (54" optional); sliding or hinged doors |
| Aerial Extension Capacity | 100' vertical 92' horizontal |
110' vertical 102' horizontal |
| Payload Capacity | 500+75 lbs dry or wet (1500 GPM flow) | 250+50 lbs dry (optional ladder pipe) |
| Stabilizers | 1x set H-style outriggers (14' spread) | 1x set H-style outriggers (14' spread) |
| Body | 96" wide modular aluminum w/ transverse compartments | 96" wide modular aluminum w/ transverse compartments |
| Pump | Waterous CXS 1500 GPM | Not Applicable |
| Tank | 300 gallons | Not Applicable |
eMAX Aerials[]
The following aerial apparatus models are available with the E-One eMAX pump:
- HP 75 Ladder
- HP 78 Ladder
- HP 100 Platform
Discontinued[]
Ladders[]
| Teleboom | HP 100 Ladder | HM 100 / HM 110 Ladder | HPS 105 Ladder | Super Tiller | |
|---|---|---|---|---|---|
| Custom Chassis | Cyclone or Typhoon | Cyclone, Quest, or Typhoon | Cyclone or Quest | Cyclone or Quest | Cyclone or Quest |
| Rear Axle / Wheelbase | Single | Tandem 230-240" |
Tandem 230" |
Tandem 240-250" |
Single 140" (tractor) |
| Vertical Reach | 50' | 100' | 100' or 110' | 105' | 100' |
| Payload Capacity | 250+50 lbs | 500+50 lbs | 500+50 lbs (HM 100) 250+50 lbs (HM 110) |
500+75 lbs | 500+50 lbs |
| Stabilizers | 1x set A-frame outriggers | 2x sets criss-cross underslung outriggers (12' spread) | 2x sets criss-cross underslung outriggers (11' spread) | 2x sets criss-cross underslung outriggers (13'-8" spread) | 1x set H-style outriggers (17'-6" spread) |
| Body Styles | Pumper | Quint Truck |
Quint Truck |
Quint Truck |
Tractor-Drawn Aerial |
| Tank Capacity | 750 US gallons | 500 US gallons | 500 US gallons | 300-500 US gallons | N/A |
Platforms[]
| HPS 100 Platform | HPS 100 Mid-Mount Platform | Bronto | |
|---|---|---|---|
| Custom Chassis | Cyclone or Quest | Cyclone or Quest | Cyclone, Quest, or Typhoon |
| Rear Axle / Wheelbase | Tandem 250-260" |
Tandem 255-265" |
Tandem 230" (F116 RLP+) or 245" (F135 RLX) |
| Vertical Reach | 100' | 100' | 116' or 135' |
| Payload Capacity | 1000+305 lbs dry 500+305 lbs wet |
1000+305 lbs dry 500+305 lbs wet |
1000+275 lbs |
| Stabilizers | 2x sets criss-cross underslung outriggers (15'-6" spread) | 1x set criss-cross underslung outriggers (18' spread), 1x set H-style outriggers (11'-7" spread) | 2x sets H-style outriggers (20' spread) |
| Body Styles | Quint Truck |
Quint Truck |
Quint Truck |
| Tank Capacity | 300-500 US gallons | 300 US gallons | 300 US gallons |
Stratospear[]
50' Stratospear[]
55' Stratospear[]
The 55' Stratospear was introduced in 1979. It was a TeleSqurt-type aerial device. It came in 2 sections, telescoping to a full 55' length. It included a lightweight aluminum ladder and was rear-mounted.
80' Stratospear[]
95' Stratospear[]
The 95' Stratospear was a telescoping ladder with an elevated platform. It was rear-mounted
106' Stratospear[]
The 106' Stratospear was a 4-section telescoping ladder. It was rear-mounted.
110' Stratospear[]
The 110' Stratospear was a 4-section telescoping ladder. It was rear-mounted.
Aircraft Rescue Firefighting[]
Current[]
- Titan 4x4
- Titan 4x4 AT (Air Transportable)
- Titan 6x6
Discontinued[]
eMAX[]
- aerials (HP 78, HP 100 ladder)
- custom pumper
- commercial pumper
- custom urban interface pumper
- commercial urban interface pumper
Pumpers[]
Current[]
- custom pumper
- commercial pumper
Discontinued[]
- E-One Liquidator (1995)
- E-One 10060 (Mini-Pumper)
- E-One 20084-TC (Rescue Pumper)
- E-One 20108-TC (Rescue Pumper)
- E-One Guardsman
- E-One Protector (198?-1990)
- E-One Sentry (198?-1993)
Rescues[]
- walk-around
- walk-in
- combination
Tankers[]
- custom tanker
- commercial tanker
- Water Master vacuum tanker
See also[]
Departments operating E-One apparatus
External links[]
Sources[]
- McCall, Walter M.P. Illustrated Encyclopedia of American Fire Engine Manufacturers. Hudson, WI: Iconografix, 2009.
